Faceted ornament gift box
Faceted ornament gift box developed as a labeled faceted paper shell. Every face and edge pairing is supplied; the assembly map is separate from cutting patterns. The fully joined shell is a display form, not a tested reusable opening container.
US Letter · 5 PDF pages · Print PDF
Go to download2 preview images · 5 PDF pages. Open the complete PDF for every page.
Preview of the actual PDF. Open complete PDF
See the page overview
READY TO PRINT
Download this printable.
- Paper
- US Letter
- Pages
- 5
- File
- Print PDF
Free · 41 KB · No account needed
Print the matching Letter/A4 edition at actual size (100%). Measure the 50 mm bar before cutting; trial-fit the parts with your chosen material.
See what is on each page
- Page 1 — Assembly instructions
- Page 2 — panel with attached tabs (18 pieces)
- Page 3 — panel with attached tabs (2 pieces)
- Page 4 — Assembly instructions
- Page 5 — Assembly instructions
Enter these page numbers in your PDF viewer’s print range. Keep any instructions, matching answers and required project pieces.
Save or prepare these pages
Optional: Studio makes a separate page using this design family and paper size. It does not edit this PDF. Preview every sheet before exporting.
Something wrong with the print?
Check the specific problem, then return to this selected PDF.
Back to the selected file · Report a problem with this printable
Faceted ornament gift box / LETTER
A good fit for your idea?
Letter and A4 preserve the component dimensions. Choose the sheet you will print, not a different object size.
Materials and construction
Plain paper for a first trial, a ruler, scissors and a blunt scoring tool; adult help for internal cuts.
Before making a batch
Measure an edge on two different faces and check matching E-labels before joining.
Assemble an empty shell and document every seam, the final closure and paper spring. Do not assume the shell is a reusable opening box.
Printing, file details and help
About this file
- Instruction pages
- 3
- Orientation
- Portrait
20 measured panel faces with 28 mm shortest edge. Edge labels identify exact mating pairs.
From file to finished page
- Cut every numbered face while retaining its shaded tabs.
- Score tab edges. Keep the panel faces flat; tabs bend behind their matching edge.
- Begin with F01 and join matching E-labels. An edge with a tab mates with the same label on a face without a tab.
- Work around the shell gradually, allowing each seam to set. Close the final panel last.
- This is a glued faceted presentation model, not a tested reusable gift closure. Confirm assembly and intended contents separately.
Printing and use notes
Panel dimensions and edge pairings are digital geometry, not a tested contents capacity or closure fit.
The fully glued faceted shell is an ornament/display form. A repeatable access lid is not supplied.
No mailing, food-contact, impact protection or load-bearing suitability is implied.
SVG downloads contain a fixed image of each PDF page. Text and shapes in the SVG are not separately editable; use the PDF for searchable text. These files are not certified cutting-machine exports.
Direct PDF files by design
Faceted ornament gift box (2 files)
- US Letter — print PDF · 5 pages
Page numbers and contents
- Page 1 — Assembly instructions
- Page 2 — panel with attached tabs (18 pieces)
- Page 3 — panel with attached tabs (2 pieces)
- Page 4 — Assembly instructions
- Page 5 — Assembly instructions
- A4 — print PDF · 5 pages
Page numbers and contents
- Page 1 — Assembly instructions
- Page 2 — panel with attached tabs (18 pieces)
- Page 3 — panel with attached tabs (2 pieces)
- Page 4 — Assembly instructions
- Page 5 — Assembly instructions
