Display-box divider study
A positioning insert for expendable lightweight samples, not a protective bottle shipping divider.
US Letter · 3 PDF pages · Print PDF
Go to download2 preview images · 3 PDF pages. Open the complete PDF for every page.
Preview of the actual PDF. Open complete PDF
See the page overview
READY TO PRINT
Download this printable.
- Paper
- US Letter
- Pages
- 3
- File
- Print PDF
Free · 6 KB · No account needed
Print the matching Letter/A4 edition at actual size (100%). Measure the 50 mm bar before cutting; trial-fit the parts with your chosen material.
See what is on each page
- Page 1 — Assembly instructions
- Page 2 — divider strip (2 pieces)
- Page 3 — Assembly instructions
Enter these page numbers in your PDF viewer’s print range. Keep any instructions, matching answers and required project pieces.
Save or prepare these pages
Optional: Studio makes a separate page using this design family and paper size. It does not edit this PDF. Preview every sheet before exporting.
Something wrong with the print?
Check the specific problem, then return to this selected PDF.
Back to the selected file · Report a problem with this printable
Display-box divider study / LETTER
A good fit for your idea?
Letter and A4 preserve the component dimensions. Choose the sheet you will print, not a different object size.
Materials and construction
Plain paper for a first trial, a ruler, scissors and a blunt scoring tool; adult help for internal cuts.
Before making a batch
Measure the 50 mm reference and at least two named panel dimensions.
Assemble an empty plain-paper trial; record closure, seam, clearance and material behavior.
Printing, file details and help
About this file
- Instruction pages
- 2
- Orientation
- Portrait
Two divider strips: 150 x 44 mm. Half-depth center slots form a nominal 150 x 150 mm cross.
Display-box divider study. A positioning insert for expendable lightweight samples, not a protective bottle shipping divider.
From file to finished page
- Cut both 150 x 44 mm strips and their half-depth center slits.
- Hold one strip with its slit upward and the other with its slit downward. Slide the slits together until the strip top and bottom edges align.
- Stand the crossed strips in an empty trial box. The cross spans 150 x 150 mm and creates four open corner areas; check the fit without bowing the strips.
Printing and use notes
A positioning insert for expendable lightweight samples, not a protective bottle shipping divider.
Nominal drawing dimensions are not a tested usable-capacity, load, mailing, food-contact or archival specification.
Do not place valuable, wet, hot or breakable items in an unreviewed paper prototype.
