Embossing Sample Sleeve package specialty project

The embossing sample sleeve has paired 70 mm faces, narrow 3 mm edges and an 8 mm joining seam.

US Letter · 3 PDF pages · Print PDF

Go to download

2 preview images · 3 PDF pages. Open the complete PDF for every page.

Page 1 of 2

Preview of the actual PDF. Open complete PDF

READY TO PRINT

Download this printable.

Paper
US Letter
Pages
3
File
Print PDF
Download PDF
Other designs or file types
Complete file list

Free · 6 KB · No account needed

For covered files: personal, classroom, noncommercial community and your own internal business records. Resale or a product incorporating a design needs separate permission. Read full use permissions.

See what is on each page
  • Page 1 — Assembly instructions
  • Page 2 — Sample sleeve blank
  • Page 3 — Assembly instructions

Enter these page numbers in your PDF viewer’s print range. Keep any instructions, matching answers and required project pieces.

Save or prepare these pages

Something wrong with the print?

Check the specific problem, then return to this selected PDF.

Back to the selected file · Report a problem with this printable

Embossing Sample Sleeve package specialty project / LETTER

A good fit for your idea?

Letter and A4 preserve the component dimensions. Choose the sheet you will print, not a different object size.

Materials and construction

Plain paper for a first trial, a ruler, scissors and a blunt scoring tool; adult help for internal cuts.

Before making a batch

Measure the 50 mm reference and at least two named panel dimensions.

Assemble an empty plain-paper trial; record closure, seam, clearance and material behavior.

Printing, file details and help

About this file

Instruction pages
2
Orientation
Portrait

Sleeve panels: 70, 3, 70 and 3 mm; depth 110 mm with 8 mm seam tab.

From file to finished page

  1. Cut the sleeve blank with its narrow seam tab attached and score the four panel boundaries.
  2. Fold the 70, 3, 70 and 3 mm panels around an expendable flat insert. Glue only the 8 mm seam tab behind the first panel and leave both ends open.
  3. Remove the insert while the sleeve dries, then check sliding clearance along the full 110 mm depth. Keep adhesive out of the sleeve.
Printing and use notes

Nominal drawing dimensions are not a tested usable-capacity, load, mailing, food-contact or archival specification.

Do not place valuable, wet, hot or breakable items in an unreviewed paper prototype.

Direct PDF files by design
Embossing Sample Sleeve package specialty project (2 files)
  • US Letter — print PDF · 3 pages
    Page numbers and contents
    • Page 1 — Assembly instructions
    • Page 2 — Sample sleeve blank
    • Page 3 — Assembly instructions
  • A4 — print PDF · 3 pages
    Page numbers and contents
    • Page 1 — Assembly instructions
    • Page 2 — Sample sleeve blank
    • Page 3 — Assembly instructions
