Paper crafts

Folded Spacer package specialty project

Two open-ended triangular paper prisms for testing a small display gap between lightweight paper surfaces.

US Letter · 2 PDF pages · Print PDF

Go to download

All 2 pages available to preview

Page 1 of 2

Preview of the actual PDF. Open complete PDF

READY TO PRINT

Download this printable.

Paper
US Letter
Pages
2
File
Print PDF
Download PDF
Other designs or file types
Complete file list

Free · 4 KB · No account needed

For covered files: personal, classroom, noncommercial community and your own internal business records. Resale or a product incorporating a design needs separate permission. Read full use permissions.

See what is on each page
  • Page 1 — triangular spacer (2 pieces)
  • Page 2 — Assembly instructions

Enter these page numbers in your PDF viewer’s print range. Keep any instructions, matching answers and required project pieces.

Save or prepare these pages

Something wrong with the print?

Check the specific problem, then return to this selected PDF.

Back to the selected file · Report a problem with this printable

Folded Spacer / LETTER

A good fit for your idea?

Letter and A4 preserve the component dimensions. Choose the sheet you will print, not a different object size.

Materials and construction

Ordinary paper for a first trial; scissors; ruler; a blunt scoring tool; a small amount of paper adhesive.

Before making a batch

Measure the three equal side panels.

Check the open ends are triangular and the seam is flush.

Record any deformation under the intended paper sample.

Printing, file details and help

About this file

Instruction pages
1
Orientation
Portrait

Each net: 75 x 68 mm.

Three equal 20 mm side panels plus an 8 mm joining tab.

Ideal triangle height: about 17.32 mm before material thickness.

From file to finished page

  1. Cut both rectangular nets. Score the three long fold lines.
  2. Fold the three equal side panels into a triangular section.
  3. Join the 8 mm tab inside the first panel without flattening the triangle.
  4. Let each prism dry with both ends open and its 75 mm length straight.
  5. Use only as a trial display spacer under a light paper sample. Inspect for collapse before any further use.
Printing and use notes

No structural, cushioning, shock-protection or shipping-load rating.

Direct PDF files by design
Folded Spacer package specialty project (2 files)
  • US Letter — print PDF · 2 pages
    Page numbers and contents
    • Page 1 — triangular spacer (2 pieces)
    • Page 2 — Assembly instructions
  • A4 — print PDF · 2 pages
    Page numbers and contents
    • Page 1 — triangular spacer (2 pieces)
    • Page 2 — Assembly instructions
